ThinkNode M2 Meshtastic (LoRa) Signal Transceiver with 1.3” OLED Display Powered By ESP32-S3 (Without Battery)

ThinkNode M2 Meshtastic (LoRa) Signal Transceiver with 1.3” OLED Display is designed for long-range mesh communication using LoRa technology with full Meshtastic firmware compatibility. Ideal for off-grid messaging, IoT communication, emergency networking, and outdoor wireless applications.

Features:

1. ESP32-S3 Dual-Core Processor
2. Compatible with Meshtastic Firmware
3. Built-in SX1262 LoRa Transceiver
4. 1.3" OLED Display
5. WiFi and Bluetooth 5.0 Connectivity
6. USB Type-C Interface
7. Low Power Operation
8. Compact Portable Design

Specifications:

Parameter	Value
Brand	ThinkNode
Model	M2 Meshtastic
Processor	ESP32-S3 Xtensa LX7 Dual-Core
Clock Frequency	Up to 240 MHz
SRAM	512KB
PSRAM	8MB
Flash	4MB
ROM	384KB
Display Size	1.3 inch
Display Type	OLED
Resolution	128 × 64
Display Driver	SSH1106
WiFi	802.11 a/b/g/n (2.4GHz)
Bluetooth	BLE + Bluetooth 5.0
LoRa Chip	SX1262
LoRa Frequency	US915 / EU868
Interface	USB Type-C, IPEX Antenna
Power Input	5V / 1A
Max Power Consumption	~217mA
Low Power Consumption	~136mA
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +60°C
Dimensions	51.5 × 37 × 9.5 mm
Weight	30 g

Package Includes:

1 x ThinkNode M2 Meshtastic (LoRa) Signal Transceiver with 1.3” OLED Display
